Especificação elétrica dos processadores Intel (CPU)

Este artigo foi publicado em 2009 e pode estar desatualizado. Para orientação técnica atual, fale com o perito.

Intel

Intel Pentium 4
Pentium 4 (Willamette) Socket 423	Core Voltage	Vmax	Max. Core Amp.	Thermal Design Power	Est. Max Power Diss.	Max. Cover Temp.
P4 1.3G (256KB)	1.7V (1.56V~1.7V)	2.1V	38.1A	48.9W	65.2W	69° C
P4 1.3G (256KB)	1.75V (1.605V~1.75V)	2.1V	39.8A	51.6W	68.8W	70° C
P4 1.4G (256KB)	1.7V (1.56V~1.7V)	2.1V	40.6A	51.8W	69.1W	70° C
P4 1.4G (256KB)	1.75V (1.6V~1.75V)	2.1V	42.2A	54.7W	72.9W	72° C
P4 1.5G (256KB)	1.7V (1.555V~1.7V)	2.1V	43A	54.7W	72.9W	72° C
P4 1.5G (256KB)	1.75V (1.595V~1.75V)	2.1V	45A	57.8W	77.1W	73° C
P4 1.6G (256KB)	1.75V (1.590V~1.75V)	2.1V	47.7A	61W	81.3W	75° C
P4 1.7G (256KB)	1.75V (1.580V~1.75V)	2.1V	50.2A	64W	85.3W	76° C
P4 1.8G (256KB)	1.75V (1.575V~1.75V)	2.1V	50.6A	66.7W	88.9W	78° C
P4 1.9G (256KB)	1.75V (1.570V~1.75V)	2.1V	52.7A	69.2W	92.3W	73° C
P4 2.0G (256KB)	1.75V (1.560V~1.75V)	2.1V	55A	71.8W	95.7W	74° C
Pentium 4 (Willamette) Socket 478	Core Voltage	Vmax	Max. Core Amp.	Thermal Design Power	Est. Max Power Diss.	Max. Cover Temp.
P4 1.4G (256KB)	1.75V (1.585V~1.75V)	2.1V	41.3A	55.3W	73.7W	72° C
P4 1.5G (256KB)	1.75V (1.580V~1.75V)	2.1V	43.5A	57.9W	77.2W	73° C
P4 1.6G (256KB)	1.75V (1.570V~1.75V)	2.1V	45.9A	60.8W	81.1W	75° C
P4 1.7G (256KB)	1.75V (1.565V~1.75V)	2.1V	48.1A	63.5W	84.7W	76° C
P4 1.8G (256KB)	1.75V (1.560V~1.75V)	2.1V	50.4A	66.1W	88.1W	77° C
P4 1.9G (256KB)	1.75V (1.545V~1.75V)	2.1V	55.2A	72.8W	97.1W	75° C
P4 2.0G (256KB)	1.75V (1.540V~1.75V)	2.1V	57.4A	75.3W	100.4W	76° C
Pentium 4 (Northwood) Socket 478	Core Voltage	Vmax	Max. Core Amp.	Thermal Design Power	Est. Max Power Diss.	Max. Cover Temp.
P4 1.6A (512KB – low watt)	1.5V (1.37V~1.5V)	1.75V	32.8A	38.7W	W	67° C
P4 1.8A (512KB – low watt)	1.5V (1.365V~1.5V)	1.75V	35.7A	41.6W	W	68° C
P4 2.0A (512KB – low watt)	1.5V (1.355V~1.5V)	1.75V	38.6A	44.6W	W	70° C
P4 1.6A (512KB)	1.5V (?V~1.5V)	1.75V	?A	46.8W	W	66° C
P4 1.8A (512KB)	1.5V (?V~1.5V)	1.75V	?A	49.6W	W	67° C
P4 2.0A (512KB)	1.475V (1.315V~1.39V)	1.75V	45.1A	54.3W	W	69° C
P4 2.0A (512KB)	1.5V (1.34V~1.415V)	1.75V	44.3A	52.4W	W	68° C
P4 2.0A (512KB)	1.525V (1.365V~1.44V)	1.75V	45.1A	54.3W	W	69° C
P4 2.2G (512KB)	1.475V (1.31V~1.385V)	1.75V	47.9A	57.1W	W	70° C
P4 2.2G (512KB)	1.5V (1.335V~1.41V)	1.75V	47.1A	55.1W	W	69° C
P4 2.2G (512KB)	1.525V (1.36V~1.435V)	1.75V	47.9A	57.1W	W	70° C
P4 2.26G (512KB)	1.475V (1.305V~1.38V)	1.75V	48.6A	58W	W	70° C
P4 2.26G (512KB)	1.5V (1.33V~1.405V)	1.75V	48A	56W	W	70° C
P4 2.26G (512KB)	1.525V (1.355V~1.435V)	1.75V	48.6A	58W	W	70° C
P4 2.4G (512KB)	1.475V (1.3V~1.38V)	1.75V	50.7A	59.8W	W	71° C
P4 2.4G (512KB)	1.5V (1.33V~1.405V)	1.75V	49.8A	57.8W	W	70° C
P4 2.4G (512KB)	1.525V (1.35V~1.43V)	1.75V	50.7A	59.8W	W	71° C
P4 2.4B (512KB)	1.475V (1.3V~1.38V)	1.75V	50.7A	59.8W	W	71° C
P4 2.4B (512KB)	1.5V (1.33V~1.405V)	1.75V	49.8A	57.8W	W	70° C
P4 2.4B (512KB)	1.525V (1.35V~1.43V)	1.75V	50.7A	59.8W	W	71° C
P4 2.4C (512KB)	1.475V (1.295V~1.375V)	1.75V	52.4A	66.2W	W	74° C
P4 2.4C (512KB)	1.5V (1.32V~1.395V)	1.75V	52.4A	66.2W	W	74° C
P4 2.4C (512KB)	1.525V (1.345V~1.42V)	1.75V	52.4A	66.2W	W	74° C
P4 2.5G (512KB)	1.475V (1.3V~1.375V)	1.75V	52A	61W	W	72° C
P4 2.5G (512KB)	1.5V (1.325V~1.4V)	1.75V	51.3A	59.3W	W	71° C
P4 2.5G (512KB)	1.525V (1.35V~1.43V)	1.75V	52A	61W	W	72° C
P4 2.53G (512KB)	1.475V (1.295V~1.325V)	1.75V	52.5A	61.5W	W	72° C
P4 2.53G (512KB)	1.5V (1.325V~1.4V)	1.75V	51.5A	59.3W	W	71° C
P4 2.53G (512KB)	1.525V (1.345V~1.43V)	1.75V	52.5A	61.5W	W	72° C
P4 2.6G (512KB)	1.475V (1.295V~1.37V)	1.75V	53.5A	62.6W	W	72° C
P4 2.6G (512KB)	1.5V (1.32V~1.4V)	1.75V	53.5A	62.6W	W	72° C
P4 2.6G (512KB)	1.525V (1.345V~1.425V)	1.75V	53.5A	62.6W	W	72° C
P4 2.6C (512KB)	1.475V (1.29V~1.37V)	1.75V	55A	69W	W	75° C
P4 2.6C (512KB)	1.5V (1.315V~1.395V)	1.75V	55A	69W	W	75° C
P4 2.6C (512KB)	1.525V (1.34V~1.42V)	1.75V	55A	69W	W	75° C
P4 2.67G (512KB)	1.475V (1.295V~1.345V)	1.75V	53.9A	66.1W	W	74° C
P4 2.67G (512KB)	1.5V (1.32V~1.395V)	1.75V	53.9A	66.1W	W	74° C
P4 2.67G (512KB)	1.525V (1.345V~1.42V)	1.75V	53.9A	66.1W	W	74° C
P4 2.8G (512KB)	1.475V (1.29V~1.37V)	1.75V	55.9A	68.4W	W	75° C
P4 2.8G (512KB)	1.5V (1.315V~1.395V)	1.75V	55.9A	68.4W	W	75° C
P4 2.8G (512KB)	1.525V (1.34V~1.42V)	1.75V	55.9A	68.4W	W	75° C
P4 2.8C (512KB)	1.475V (1.288V~1.369V)	1.75V	55.9A	69.7W	W	75° C
P4 2.8C (512KB)	1.5V (1.313V~1.394V)	1.75V	55.9A	69.7W	W	75° C
P4 2.8C (512KB)	1.525V (1.338V~1.419V)	1.75V	55.9A	69.7W	W	75° C
P4 3.0C (512KB)	1.475V (1.265V~1.35V)	1.75V	64.8A	81.9W	W	70° C
P4 3.0C (512KB)	1.5V (1.29V~1.375V)	1.75V	64.8A	81.9W	W	70° C
P4 3.0C (512KB)	1.525V (1.315V~1.4V)	1.75V	64.8A	81.9W	W	70° C
P4 3.0C (512KB)	1.55V (1.34V~1.425V)	1.75V	64.8A	81.9W	W	70° C
P4 3.06G (512KB)	1.475V (1.265V~1.345V)	1.75V	65.4A	81.8W	W	69° C
P4 3.06G (512KB)	1.5V (1.29V~1.37V)	1.75V	65.4A	81.8W	W	69° C
P4 3.06G (512KB)	1.525V (1.315V~1.395V)	1.75V	65.4A	81.8W	W	69° C
P4 3.06G (512KB)	1.55V (1.34V~1.425V)	1.75V	65.4A	81.8W	W	69° C
P4 3.2C (512KB)	1.475V (1.26V~1.345V)	1.75V	67.4A	82W	W	70° C
P4 3.2C (512KB)	1.5V (1.285V~1.37V)	1.75V	67.4A	82W	W	70° C
P4 3.2C (512KB)	1.525V (1.31V~1.395V)	1.75V	67.4A	82W	W	70° C
P4 3.2C (512KB)	1.55V (1.335V~1.42V)	1.75V	67.4A	82W	W	70° C
P4 3.4C (512KB)	1.475V (1.28V~1.35V)	1.75V	71.6A	89W	W	68° C
P4 3.4C (512KB)	1.5V (1.305V~1.375V)	1.75V	71.6A	89W	W	68° C
P4 3.4C (512KB)	1.525V (1.33V~1.4V)	1.75V	71.6A	89W	W	68° C
P4 3.4C (512KB)	1.55V (1.355V~1.425V)	1.75V	71.6A	89W	W	68° C
